178 Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 12 ASCII Serial Communications
Figure 61 - SUMMARY Command - Example
SUMMARY R (Level 1 and 2)
The SUMMARY R command clears all the events in the event buffer.
TARGET (Level 1 or 2)
The TARGET command displays the status of relay elements whether they are
asserted or de-asserted. The elements are represented as Relay Status bits and are
listed in rows of eight, called Relay Status rows. For additional information on
individual Relay Status bits, refer to AppendixC
, Relay Word Bits.
A Relay Word bit is either at logical 1 (asserted) or at logical 0 (de-asserted).
The TAR command options are listed in Table 106.
Table 107 - Front-Panel LEDs and the TAR 0 Command
Table 106 - TARGET Command Options
Commands Descriptions
TAR n k Shows Relay Word Row n (0–10).
k is an optional parameter to specify the number of times (1–32767) to repeat the Relay Word
row display.
If k is not specified, the Relay Word row is displayed once.
See Table 106 for the definition of Row 0.
See Table for a list of the Relay Word bits in each row (n = 1–10).
TAR name k Shows the Relay Word bit row containing the Relay Word bit name (e.g., TAR 50P1T displays
Relay Word Row 1).
Valid names are shown in TARGET R (Level 2) on page 179.
k is an optional parameter to specify the number of times (1–32767) to repeat the Relay Word
bit row display.
If k is not specified, the Relay Word row is displayed once.
LED Number/State 7 6 543210
ALARM (Flashing) N/A WARNING N/A N/A N/A N/A N/A N/A
ON Steady (Latched) ENABLE TRIP N/A N/A N/A N/A N/A N/A
=>>SUM 2
825-P Modular Date: 02/04/2003 Time: 17:20:46.439
Prot. System
Event #: 1 Event: OVERLOAD TRIP
Event Date: 01/29/2003 Event Time: 14:14:01.930
L1 L2 L3 RES CB
CURRENT MAG (A) 8.2 8.1 8.2 0.0 0.00
Event #: 2 Event: OVERLOAD TRIP
Event Date: 01/29/2003 Event Time: 14:13:05.931
L1 L2 L3 RES CB
CURRENT MAG (A) 8.2 8.2 8.2 0.0 0.00
=>>
