Rockwell Automation Publication 825-UM004D-EN-P - November 2012 113
Chapter 9
825-PDN DeviceNet Communication Card
Introduction
The 825-PDN DeviceNet Communication Card is an optional accessory that
enables connection of the 825-P Modular Protection System to the DeviceNet
automation network. The card occupies the communication expansion slot
(Slot C) in the 825-P Modular Protection System.
Figure 38 - 825-P Modular Protection System Back Panel View
Communication Expansion Slot
