242 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter E DeviceNet Information
Electronic Data Sheets
Electronic Data Sheet (EDS) files are specially formatted ASCII files that provide
all of the information necessary for a configuration tool (e.g., RSNetWorx for
DeviceNet) to access and alter the parameters of a device. The EDS file contains
all the parameter information of a device: number of parameters, groupings,
parameter name, min, max, and default values, units, data format and scaling.
EDS files are available from the Internet at www.ab.com/networks/eds/index/
html. They can also be built automatically by some configuration tools since all of
the information necessary for an EDS file can be extracted from the 825-P
Modular Protection System.
Product Codes
Configuration tools use product codes to identify which EDS file to use for a
given device. The 825-P Modular Protection System has a product code of
100(64 hex).
DeviceNet Objects
The 825-P Modular Protection System supports the following DeviceNet object
classes:
Table 114 - DeviceNet Object Classes
Class Object
0x0001 Identity
0x0002 Message Router
0x0003 DeviceNet
0x0004 Assembly
0x0005 Connection
0x0008 Discrete Input Point
0x0009 Discrete Output Point
0x000F Parameter Object
0x0010 Parameter Group Object
0x001E Discrete Output Group
0x0029 Control Supervisor
0x002B Acknowledge Handler
0x002C Overload Object
0x00B4 DN Interface Object
0x00C2 PCP Object
