Page #193 background imageLoading...
Page #193 background image
Rockwell Automation Publication 825-UM004D-EN-P - November 2012 193
Appendix B
Parameter List
Overview
This appendix lists all accessible parameters of the 825-P relay in numerical order.
The setting range for each parameter is provided to assist especially for
applications where it is desirable to set values from a logic controller via a network
connection.
Information values provided include the following:
Value Function
Setting Range Indicated as raw numerical values.
Scale Factor Indicate the decimal precision associated with each parameter. This must be given close attention
when writing or reading values.
Default Indicate the factory pre-programmed values.
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
Status
1 HDW INPUTS 0 = IN1 0 Get
1 = IN2 0
2 = IN3 0
3 = IN4 0
4 = IN5 0
5 = IN6 0
6 = IN7 0
7 = IN8 0
2HDW OUTPUTS0 = AUX10Get
1 = AUX2 0
2 = AUX3 0
3 = AUX4 0
4 = AUX5 0
5 = AUX6 0
