Allen-Bradley 825-P User Manual

194 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter B Parameter List
Status
(cont.)
3 TRIP STATUS 1 0 = Overload 0 — — Get
1 = Undercurrent 0
2 = Jam 0
3 = Curr.Imballance 0
4 = Short Circuit 0
5 = RTD - Wind/Bear 0
6 = PTC 0
7 = GF - Residual 0
8 = VAR 0
9 = Underpower 0
10 = Undervoltage 0
11 = Overvoltage 0
12 = Phase Reversal 0
13 = Power Factor 0
14 = Speed Switch 0
15 = GF - Core Bal. 0
4 TRIP STATUS 2 0 = Start Time 0 — — Get
1 = Frequency 1 0
2 = Frequency 2 0
3 = RTD - Other 0
4 = RTD - Ambient 0
5 = PTC Error 0
6 = RTD Error 0
7 = MCM Error 0
8 = Comm Idle 0
9 = Comm Loss 0
10 = Remote Trip 0
11 = Comm Fault 0
12 = Alarm - Critical 0
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
