Rockwell Automation Publication 825-UM004D-EN-P - November 2012 241
Appendix E
DeviceNet Information
Section Page
Electronic Data Sheets 242
Product Codes 242
DeviceNet Objects 242
Identity Objects - CLASS CODE 0x0001 243
Message Router - CLASS CODE 0x0002 244
DeviceNet Object - CLASS CODE 0x0003 244
Assembly Object - CLASS CODE 0x0004 245
Custom Parameter-Based Input (Produced) Assembly Instance 100 246
Standard Input (Produced) Assemblies 247
Standard Output (Consumed) Assemblies 250
Connection Object - CLASS CODE 0x0005 251
Discrete Input Point Object - CLASS CODE 0x0008 254
Discrete Output Point Object - CLASS CODE 0x0009 255
Discrete Output Point Object Special Requirements 256
State Transition Diagram 256
Parameter Object - CLASS CODE 0x000F 257
Parameter Group Object - CLASS CODE 0x0010 258
Discrete Output Group Object - CLASS CODE 0x001E 259
Control Supervisor Object - CLASS CODE 0x0029 261
Acknowledge Handler Object - CLASS CODE 0x002b 261
Overload Object - CLASS CODE 0x002c 262
DeviceNet Interface Object - CLASS CODE 0x00B4 262
