Chapter D ASCII Port Relay Command Summary
SHO P 1, 2 Show Serial Port F settings.
SHO M 1, 2 Show I/O mapping settings.
STA 1, 2 Display relay self-test status.
STA R or C 2 Clear self-test status and restart relay.
STO 2 Stop motor.
STR 2 Start motor.
SUM 1, 2 View event summary reports.
SUM R or C 1, 2 Reset event summary buffer.
TAR 1, 2 Display Relay Word Row 0 (front panel target LEDs).
TAR n k 1, 2 Display Relay Word Row n (n = 0…10). Repeat k times.
TAR name k 1, 2 Display Relay Word Row containing Relay Word name. Repeat k times.
TAR R 2 Reset front panel trip/target LEDs.
TIM 1, 2 View time.
TIM hh:mm:ss 1, 2 Set time by entering TIM followed by hours, minutes, and seconds, as shown (24-hour clock).
