260 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter E DeviceNet Information
Instance 3 contains the following attributes:
Instance 4 contains the following attributes:
The following common services are implemented for the Discrete Input Group
Object:
Attribute ID Access Rule Name Data Type Value
3 Get Number of
Instances
USINT 10
4 Get Binding Array of UINT 1, 2
7 Get/Set Fault Action BOOL 0=Fault Value attribute, 1=Hold Last State
8 Get/Set Fault Value BOOL 0=OFF, 1=ON
9 Get/Set Idle Action BOOL 0=Fault Value attribute, 1=Hold Last State
10 Get/Set Idle Value BOOL 0=OFF, 1=ON
113 Get/Set Pr Fault Action BOOL 0=Fault Value attribute, 1=Hold Last State
114 Get/Set Pr Fault Value BOOL 0=OFF, 1=ON
Attribute ID Access Rule Name Data Type Value
3 Get Number of
Instances
USINT 4
4 Get Binding Array of UINT 3, 4, 5, 6
7 Get/Set Fault Action BOOL 0=Fault Value attribute, 1=Hold Last State
8 Get/Set Fault Value BOOL 0=OFF, 1=ON
9 Get/Set Idle Action BOOL 0=Fault Value attribute, 1=Hold Last State
10 Get/Set Idle Value BOOL 0=OFF, 1=ON
113 Get/Set Pr Fault Action BOOL 0=Fault Value attribute, 1=Hold Last State
114 Get/Set Pr Fault Value BOOL 0=OFF, 1=ON
Attribute ID Access Rule Name Data Type Value
3 Get Number of
Instances
USINT 4
4 Get Binding Array of UINT 7, 8, 9, 10
7 Get/Set Fault Action BOOL 0=Fault Value attribute, 1=Hold Last State
8 Get/Set Fault Value BOOL 0=OFF, 1=ON
9 Get/Set Idle Action BOOL 0=Fault Value attribute, 1=Hold Last State
10 Get/Set Idle Value BOOL 0=OFF, 1=ON
113 Get/Set Pr Fault Action BOOL 0=Fault Value attribute, 1=Hold Last State
114 Get/Set Pr Fault Value BOOL 0=OFF, 1=ON
