Rockwell Automation Publication 825-UM004D-EN-P - April 2012 263
DeviceNet Information Chapter E
Attribute ID Access
Rule
Name Data
Type
Min/Max Default Description
7 Get/Set Prod Assy Word 0 UINT 1 Defines Word 0 of Assy 100
8 Get/Set Prod Assy Word 1 UINT 5 Defines Word 1 of Assy 100
9 Get/Set Prod Assy Word 2 UINT 6 Defines Word 2 of Assy 100
10 Get/Set Prod Assy Word 3 UINT 7 Defines Word 3 of Assy 100
15 Get/Set Autobaud Enable BOOL 0…1 1 1= enabled; 0 = disabled
16 Get/Set Consumed Assy USINT 0…185 150
17 Get/Set Produced Assy USINT 0…185 103
19 Get/Set Set To Defaults BOOL 0…1 0 0=No action; 1=Reset
23 Get I/O Produced Size USINT 0…16 Read only
24 Get I/O Consumed Size USINT 0…8 Read only
30 Get DeviceNet Voltage UINT Read only
50 Get/Set PNB COS Mask WORD 0…0x00FF 0 Change of state mask for PNBs
55 Get/Set Prod Assy Word 4 UINT 0 Defines Word 4 of Assy 100
56 Get/Set Prod Assy Word 5 UINT 0 Defines Word 5 of Assy 100
57 Get/Set Prod Assy Word 6 UINT 0 Defines Word 6 of Assy 100
58 Get/Set Prod Assy Word 7 UINT 0 Defines Word 7 of Assy 100
65 Get/Set Status COS Mask 1 UINT 0…ffff 0
66 Get/Set Status COS Mask 2 UINT 0…ffff 0
67 Get/Set Trip COS Mask 1 UINT 0…ffff 0
68 Get/Set Trip COS Mask 2 UINT 0…ffff 0
69 Get/Set Warning COS Mask 1 UINT 0…ffff 0
70 Get/Set Warning COS Mask 2 UINT 0…ffff 0
