Allen-Bradley 825-P User Manual

42 Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 3 Front Panel Operation
Figure 27 - Front Panel Setting Entry Example
Main Menu
Meter
Events
Motor Monitor
Targets
Set/Show
Status
Reset TCU
Set/Show Menu
RELAY
PORT
IO ASSIGN
DATE/TIME
PASSWORD
RELAY Menu
Main Settings
Overload Set
•
•
•
Front Panel Set
Display Enable
Main Settings Menu
UNIT ID LN 1
UNIT ID LN 2
PH ROTATION
RATED FREQ
•
•
•
LINE VOLTAGE
XFMR CON
PHASE
ROTATION Menu
PHROT=ABC
Press to move
within the list.
Press to return
to the previous list.
Press to select an
underlined menu item.
ESC
ESC
ESC
ESC
