A-14 Valid CommMethod and ConfigMethod Values
1794 Modules
This table lists the valid CommMethod and ConfigMethod values for
1794 modules.
I/O Module: Configuration: CommMethod Value: ConfigMethod Value:
1794-ACN15 None 20000002 na
Rack Optimized 30000001 00800001
1794-ACNR15 None 20000002 na
Rack Optimized 30000001 00800001
1794-AENT None 20000002 na
Rack Optimized 30000001 00800001
1794-ASB Rack 20000001 00800001
1794-IA16 Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IA8 Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IA8I Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IB16 Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IB32 Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IB8 Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IB8S Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IB10XOB6 Data 20000001 00800001
Listen Only - Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IB16XOB16P Data 20000001 00800001
Listen Only - Data 28000002 00800002
Rack Optimized 40000000 00800003
1794-IBN16 Input Data 20000001 00800001
Listen Only - Input Data 28000002 00800002
Rack Optimized 40000000 00800003
