Structuring a Complete (.L5K) Import/Export File Format 2-5
Specifying CONTROLLER attributes
You can specify these attributes for a CONTROLLER:
Attribute: Description:
Description
Provide information about the controller.
Specify:
Description := ” text ”
ProcessorType
Specify the type of controller (1756-L1, 1756-L53, 1756-L55, 1756-L63, 1769-L20,
1769-L30, 1789-L60, 1794-L33, 1794-L34, PowerFlex700S)
Specify:
ProcessorType := name
Major
Specify the major revision number (1-127) of the controller.
Specify:
Major := number
TimeSlice
Percentage of available CPU time (10-90) that is assigned to communications.
Specify:
TimeSlice := value
PowerLossProgram
Name of the program to be executed on reboot after a power loss.
Specify:
PowerLossProgram := name
MajorFaultProgram
Name of the program to be executed when a major fault occurs.
Specify:
MajorFaultProgram := name
CommPath
List of the devices in the communication path. The communication path ends with the
controller (
\Backplane\1).
Specify:
CommPath := device\device\device... \Backplane\1
SecurityCode
Specify whether the RSI Security Server is enabled for the controller. Enter 0 if the
controller is unsecured; enter -1 the controller is secured.
Specify: SecurityCode
:= text
RedundancyEnabled
Specify whether redundancy is used or not. Enter a 0 to disable redundancy; enter a 1 to
enable redundancy.
Specify:
RedundancyEnabled := number
KeepTestEditsOnSwitchOver
Specify whether to keep test edits on when a switchover occurs (only in a redundant
system). Enter a 0 not to keep test edits on; enter a 1 to keep test edits on.
Specify:
KeepTestEditsOnSwitchOver := number
DataTablePadPercentage
Specify the amount of data table to reserve. If redundancy is not enabled, enter 0. If
redundancy is enabled, enter 50.
Specify:
DataTablePadPercentage := name
SFCExecutionControl
Specify whether the SFC executes the current active steps before returning control
(CurrentActive) or whether the SFC executes all threads until reaching a false transition
(UntilFalse).
Specify:
SFCExecutionControl := name
SFCRestartPosition
Specify whether the SFC restarts at the most recently executed step (MostRecent) or at
the initial step (InitialStep).
Specify:
SFCRestartPosition := name
SFCLastScan
Specify how the SFC manages its state on last scan. Select AutomaticReset,
ProgrammaticReset, or DontScan.
Specify:
SFCLastScan := name
