7-20 Entering Sequential Function Chart Logic
DIRECTED_LINK guidelines
•
All DIRECTED_LINK blocks must come after all STEP,
TRANSITION, STOP, and BRANCH blocks.
•
A directed link links only one element to one other element.
DIRECTED_LINK example
DIRECTED_LINK (FromElementID := 16, ToElementID := 12, ShowLink := True)
END_DIRECTED_LINK
Entering Text Boxes
The text box blocks in an SFC routine hold descriptions about SFC
components. Text boxes follow this format:
TEXT_BOX (
ID := <
unique_identifier >,
X := <
internal_grid_x_location >,
Y := <
internal_grid_y_location >,
Width := <
numerical_value >
Text := <“
text ”>)
END_TEXT_BOX
Where:
Item: Identifies:
ID
the text box identifier. This ID uniquely identifies this text box from all other blocks. Enter
an unsigned, 32-bit integer value.
Specify:
ID := number
X
x-coordinate on internal grid. Enter an unsigned, 32-bit integer value.
Specify:
X := number
Y
y-coordinate on internal grid. Enter an unsigned, 32-bit integer value.
Specify:
Y := number
Width
this attribute is not currently used; it is there for future use. Enter 0.
Specify:
Width := 0
Text
the descriptive text.
Specify:
Text := text
