Valid CommMethod and ConfigMethod Values A-17
PowerFlex Modules
This table lists the valid CommMethod and ConfigMethod values for
PowerFlex modules.
Drives and Motion
This table lists the valid CommMethod and ConfigMethod values for
drives and motion modules.
I/O Module: Configuration: CommMethod Value: ConfigMethod Value:
PowerFlex 70-C Data 20000001 00800001
PowerFlex 700-200V-C Data 20000001 00800001
PowerFlex 700-400V-C Data 20000001 00800001
PowerFlex 700-600V-C Data 20000001 00800001
PowerFlex 700S-200V Velocity Control 20000001 00800001
Position Control 20000002 00800002
User-Defined Control 20000003 00800003
PowerFlex 700S-200V-C Data 20000001 00800001
PowerFlex 700S-400V Velocity Control 20000001 00800001
Position Control 20000002 00800002
User-Defined Control 20000003 00800003
PowerFlex 700S-400V-C Data 20000001 00800001
PowerFlex 700S-600V Velocity Control 20000001 00800001
Position Control 20000002 00800002
User-Defined Control 20000003 00800003
PowerFlex 700S-600V-C Data 20000001 00800001
PowerFlex 700SE-200V User-Defined Control 20000003 00800001
PowerFlex 700SE-400V User-Defined Control 20000003 00800001
PowerFlex 700SE-600V User-Defined Control 20000003 00800001
I/O Module: Configuration: CommMethod Value: ConfigMethod Value:
1305-ACDrive-CN1 Data 20000001 na
1336E-IMPACTDrive-CN1 Data 20000001 na
1336F-PLUSIIDrive-CN1 Data 20000001 na
1336R-REGENBrake-CN1 Data 20000001 na
1336S-PLUSDriveLG-CN1 Data 20000001 na
1336S-PLUSDriveSM-CN1 Data 20000001 na
1336T Data 20000001 na
1336T-FORCEDriveCNA-CN1 Data 20000001 na
1336T-FORCEDrivePLC-CN1 Data 20000001 na
1336T-FORCEDriveStd-CN1 Data 20000001 na
1394C-SJT05-D Data 20000001 00800001
1394C-SJT10-D Data 20000001 00800001
1394C-SJT22-D Data 20000001 00800001
1395 Data 20000001 na
