Allen-Bradley ControlLogix 1756 User Manual

Publication 1756-RM084F-EN-P - July 2002
Entering Function Block Diagram Logic 5-5
OREF (ID := 5,
X := 520,
Y := 320,
Operand := Output_Tag)
END_OREF
OCON (ID := 6,
X := 680,
Y := 100,
Name := ConnectorName)
END_OCON
FEEDBACK_WIRE (FromElementID := 0,
FromParameter := Dest,
ToElementID := 0,
ToParameter := SourceB)
END_FEEDBACK_WIRE
WIRE (FromElementID := 3,
FromParameter := "",
ToElementID := 1,
ToParameter := In)
END_WIRE
WIRE (FromElementID := 4,
FromParameter := "",
ToElementID := 2,
ToParameter := In)
END_WIRE
WIRE (FromElementID := 0,
FromParameter := Dest,
ToElementID := 6,
ToParameter := "")
END_WIRE
