Allen-Bradley Kinetix 5700 Series User Manual

Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 285
Troubleshoot the Kinetix 5700 Drive System Chapter 7
FLT S31 – BUS REG FAILURE Bus Regulator Failure –––X
FLT S32 – BUS CAPACITOR MODULE FAILUREBus Capacitor Module Failure XXXX
FLT S35 – BUS OVERVOLT FL Bus Overvoltage Factory Limit Fault –––X
FLT S40 – BUS POWER SHARING FAULTBus Power Sharing Fault –––X
FLT S61 – ENABLE INPUT Enable Input Deactivated –––X
(1) Supported when shunt thermal switch is connected to the power supply digital input and configured in the Logix Designer application.
Table 133 - DC-bus Power Supply Behavior, FLT Sxx Fault Codes (continued)
Exception Fault Code Exception Text
Fault Action
Ignore Alarm Minor Fault Major Fault
Table 134 - DC-bus Power Supply Behavior, FLT Mxx Fault Codes
Exception Fault Code Exception Text
Fault Action
Ignore Alarm Minor Fault Major Fault
FLT M12 – POWER CYCLE FL
(1)
Converter Precharge Overload Factory Limit Fault–––X
FLT M26 – RUNTIME ERROR Runtime Error –––X
(1) Single-axis and dual-axis drives assert Bus Power Sharing Exception.
Table 135 - DC-bus Power Supply Behavior, NODE FLT Fault Codes
Exception Fault Code Exception Text
Permanent
Magnet Motor
Induction
Motor
Fault Action
Best Available
Stopping Action
(applies to major faults)
Ignore Alarm Minor Fault Major Fault
NODE FLT 01 – LATE CTRL UPDATE Control Connection Update FaultX X –––XDecel/Disable
NODE FLT 02 – PROC WATCHDOG Processor Watchdog Fault X X –––XDisable/Coast
NODE FLT 03 – HARDWARE Hardware Fault X X –––X Disable/Coast
NODE FLT 05 – CLOCK SKEW FLT Clock Skew Fault X X –––X Decel/Disable
NODE FLT 06 – LOST CTRL CONN Lost Controller Connection FaultX X –––XDecel/Disable
NODE FLT 07 – CLOCK SYNC Clock Sync Fault X X –––X Decel/Disable
NODE FLT 09 – DUPLICATE IP ADDRESSDuplicate IP Address Fault X X –––XDisable/Coast
