Allen-Bradley Kinetix 5700 Series User Manual

Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 287
Troubleshoot the Kinetix 5700 Drive System Chapter 7
FLT S23 – AC PHASE LOSS AC Single Phase Loss Fault –––X
FLT S25 – PRECHARGE FAILURE Precharge Failure Fault –––X
FLT S27 – BUS REG OVERTEMP FL
(1)
Bus Regulator Overtemperature Factory Limit Fault–––X
FLT S32 – BUS MODULE FAILURE Bus Module Failure XXXX
FLT S35 – BUS OVERVOLT FL Bus Overvoltage Factory Limit Fault –––X
FLT S58 – EXCESSIVE BUS VOLTAGE ERRORExcessive Bus Voltage Error –––X
FLT S61 – ENABLE INPUT Enable Input Deactivated –––X
FLT S64 – AC LINE OVERVOLTAGE FLAC Line Overvoltage FL –––X
FLT S66 – AC LINE UNDER VOLTAGE FL
(2)
AC Line Undervoltage FL –––X
FLT S68 – AC LINE HIGH FREQUENCY FLAC Line High Frequency FL –––X
FLT S70 – AC LINE LOW FREQUENCY FLAC Line Low Frequency FL –––X
FLT S72 – AC LINE VOLTAGE UNBALANCEAC Line Voltage Unbalance –––X
FLT S73 – AC LINE CURRENT UNBALANCEAC Line Current Unbalance –––X
FLT S74 – AC LINE VOLTAGE SAG
(2)
AC Line Voltage Sag –––X
FLT S75 – AC LINE FREQUENCY CHANGEAC Line Frequency Change –––X
FLT S76 – AC LINE SYNCHRONIZATION LOSS
(2)
AC Line Synchronization Loss –––X
FLT S76 – AC LINE SYNCHRONIZATION FAILUREAC Line Synchronization Failure –––X
(1) Supported when shunt thermal switch is connected to the power supply digital input and configured in the Logix Designer application.
(2) A single or three-phase open circuit can result in a number of different faults depending on the converter loading.
Table 136 - Regenerative Bus Supply Behavior, FLT Sxx Fault Codes (continued)
Exception Fault Code Exception Text
Fault Action
Ignore Alarm Minor Fault Major Fault
Table 137 - Regenerative Bus Supply Behavior, FLT Mxx Fault Codes
Exception Fault Code Exception Text
Fault Action
Ignore Alarm Minor Fault Major Fault
FLT M12 – POWER CYCLE FL
(1)
Converter Precharge Overload Factory Limit Fault – – – X
FLT M26 – RUNTIME ERROR Runtime Error – – – X
FLT M29 – AC LINE CONTACTOR AC Line Contactor – – – X
FLT M30 – AC LINE RESONANCE FL AC Line Resonance FL – – – X
(1) Single-axis and dual-axis inverters assert Bus Power Sharing Exception.
