Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 55
Plan the Kinetix 5700 Drive System Installation Chapter 2
Table 18 - Power Dissipation Specifications
DC-bus Power Supply Cat. No.
Usage as % of Rated Power Output
(watts)
20% 40% 60% 80% 100%
2198-P031 97 101 105 109 113
2198-P070 108 119 130 140 151
2198-P141 249 267 286 304 323
2198-P208 265 294 323 352 380
Regenerative Bus Supply Cat. No.
2198-RP088 253 399 544 690 835
2198-RP200 532 832 1132 1432 1732
2198-RP263 850 1261 1672 2083 2494
2198-RP312 1037 1576 2115 2654 3193
Dual-axis Inverter Cat. No.
2198-D006-ERSx 17 29 41 53 65
2198-D012-ERSx 34 58 82 106 130
2198-D020-ERSx 52 84 116 148 180
2198-D032-ERSx 100 155 210 265 320
2198-D057-ERSx 252 354 456 558 660
Single-axis Inverter Cat. No.
2198-S086-ERSx 190 255 325 400 475
2198-S130-ERSx 225 340 460 590 725
2198-S160-ERSx 270 420 570 760 950
2198-S263-ERSx 556 759 989 1245 1529
2198-S312-ERSx 610 883 1200 1561 1965
iTRAK Power Supply Cat. No.
2198T-W25K-ER 206 272 338 404 470
Capacitor Module Cat. No.
2198-CAPMOD-2240 28 34 42 51 62
2198-CAPMOD-DCBUS-IO 1.1 1.4 1.6 2.1 2.5
DC-bus Conditioner Module Cat. No.
2198-DCBUSCOND-RP312 1.4 2.1 3.2 4.7 6.7
To Next Page
