Allen-Bradley Micro800 2080-MEMBAK-RTC2 User Manual

18 Rockwell Automation Publication 2080-UM004D-EN-E - March 2018
Chapter 2 Install and Wire Your Module
Kinetix 300 in feedback configuration to 2080-MOT-HSC
Micro830/Micro850 QBB (24 pts)
PTO
I/O Connector
49 = 24V_PULS+
12 = PLUS-
14 = SIGN-
25 = 24V_SIGN+
I/O Connector
29 = AM+
30 = AM-
31 = BM+
32 = BM-
1
2
3
4
FEEDBACK
A+
A-
B+
B-
O-00
-CM0
-CM1
O-03
7
8
9
10

Allen-Bradley Micro800 2080-MEMBAK-RTC2 Specifications

General

Brand	Allen-Bradley
Model	Micro800 2080-MEMBAK-RTC2
Category	Control Unit
Language	English
