Chapter 4 High Speed Counter – 2080-MOT-HSC
Differences Between
Embedded HSC and Plug-in
Module
The following table lists the differences between the embedded HSC and the
2080-MOT-HSC plug-in module.
Counter Specifications
Filter and decode inputs: 3 input points A, B, Z
These input points may come from different types and configurations of sensors.
The user must configure the module to respond to the type of sensor connected
to the module as described below. This can be configured in the 2080-MOT-
HSC UDFB. From Connected Components Workbench Release 8.0 onwards, if
you have configured the plug-in for Feedback Axis, you can also edit the input
filter values in the plug-in configuration module properties.
Embedded HSC 2080-MOT-HSC Plug-in Module
Limited to 100 kHz Up to 250 kHz
12/24V input 12/24V input or 5V differential line driver
None Embedded rate calculation using “Per Pulse” and
“Cyclic” methods
Dedicated preset and hold inputs Configure either preset or hold inputs
None One 5/24V output
When using the 2080-MOT-HSC module, the high and low preset
status does not automatically reset. When using the embedded HSC,
it automatically resets when the high and low preset condition no
longer exists.
Nominal Filter Settings Maximum Guaranteed
Block Pulse Width
Minimum Guaranteed Pass
Pulse Width
No Filter – Default – –
250 kHz (DC 2 µs) 617 kHz (DC 0.81 µs) 263kHz (DC 1.9 µs)
200 kHz (DC 2.5 µs) 352 kHz (DC 1.42 µs) 201 kHz (DC 2.48 µs)
80 kHz (DC 6.25 µs) 135 kHz (DC 3.7 µs) 86.2 kHz (DC 5.8 µs)
40 kHz (DC 12.5 µs) 62.5 kHz (DC 8.0 µs) 42.5 kHz (DC 11.76 µs)
13.3 kHz (DC 37.6 µs) 20.8 kHz (DC 24.1 µs) 14.1 kHz (DC 35.5 µs)
10 kHz (DC 50 µs) 15.7 kHz (DC 31.8 µs) 10.5 kHz (DC 47.2 µs)
4 kHz (DC 125 µs) 6.3 kHz (DC 79.3 µs) 4.2 kHz (DC 119 µs)
2 kHz (DC 250 µs) 3.2 kHz (DC 156 µs) 2.1 kHz (DC 237 µs)
1 kHz (DC 0.5 ms) 1.6 kHz (DC 0.31 ms) 1.0 kHz (DC 0.5 ms)
500 Hz (DC 1 ms) 778 Hz (DC 0.642 ms) 526 Hz (DC 0.95 ms)
250 Hz (DC 2 ms) 389 Hz (DC 1.285 ms) 263 Hz (DC 1.9 ms)
125 Hz (DC 4 ms) 195 Hz (DC 2.6 ms) 131 Hz (DC 3.81 ms)
62.5 Hz (DC 8 ms) 97.3 Hz (DC 5.14 ms) 65.8 Hz (DC 7.6 ms)
31.25 Hz (DC 16 ms) 48.5 Hz (DC 10.3 ms) 32.9 Hz (DC 15.2 ms)
50% duty
