Rockwell Automation Publication 2080-UM004D-EN-E - March 2018 55
DeviceNet Plug-in – 2080-DNET20 Chapter 5
RA_DNET_OVERLOAD
This UDFB is used for I/O data exchange with an overload relay.
RA_DNET_GENERIC
This UDFB is used for I/O data exchange with generic I/O devices.
PF_Alarm OUTPUT BOOL[1...5] Alarm bit from PowerFlex drive.
Each element of the array corresponds to each
drive, for example, PF_Alarm[1] for Drive 1 and
PF_Alarm[5] for Drive5.
PF_Fault OUTPUT BOOL[1...5] Fault bit from PowerFlex drive.
Each element of the array corresponds to each
drive, for example, PF_Fault[1] for Drive 1 and
PF_Fault[5] for Drive5.
PF_AltReference OUTPUT BOOL[1...5] Alt Reference bit from PowerFlex drive.
Each element of the array corresponds to each
drive, for example, PF_AltReference[1] for
Drive 1 and PF_AltReference[5] for Drive5.
IMPORTANT
Ensure that your PowerFlex drives settings are correct. For basic setup
configuration, see the PowerFlex drives user manuals in the
Rockwell Automation Literature Library
.
RA_DNET_OVERLOAD: Input and Output Parameters
Variable Name Type Data Type Description
FBEN INPUT BOOL Function block enable input.
TRUE to enable the function.
SlotID INPUT UINT Plug-in slot number (1…5 for plug-in slots).
NodeID INPUT USINT DeviceNet node address of the slave node.
OutA INPUT BOOL TRUE to turn on Output A.
TripReset INPUT BOOL TRUE to enable Trip Reset.
FBENO OUTPUT BOOL Function block enable output.
TRUE upon exit.
IN1 OUTPUT BOOL Input 1 from overload relay.
IN2 OUTPUT BOOL Input 2 from overload relay.
Warning OUTPUT BOOL TRUE if warning is enabled.
Tripped OUTPUT BOOL TRUE if tripped.
AverageFLA OUTPUT WORD Average FLA % value from overload relay.
ThermUtilized OUTPUT WORD Therm Utilized value from overload relay.
OutAStatus OUTPUT WORD Average FLA value from overload relay.
RA_PF_DNET_MULTIDRIVE: Input and Output Parameters
Variable Name Type Data Type Description
RA_DNET_OVERLOAD
FBEN
SlotID
NodeID
OutA
TripReset
FBENO
IN1
IN2
Warning
Tripped
AverageFLA
ThernUtilized
OutAStart
RA_DNET_GENERIC
FBEN
SlotID
NodeID
OutputData
FBENO
InputData
