Rockwell Automation Publication 2080-UM004D-EN-E - March 2018 67
Specifications Appendix A
Analog Plug-in Modules
Certifications – 2080-OW4I
Certification (when
product is marked)
(1)
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for
Declarations of Conformity, Certificates, and other certification details.
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada.
See UL File E322657.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,
certified for U.S. and Canada. See UL File E334470.
CE European Union 2014/30/EU EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2014/35/EU LVD, compliant with:
EN 61131-2; Programmable Controllers (Clause 11)
RCM Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
KC Korean Registration of Broadcasting and Communications
Equipment, compliant with:
Article 58-2 of Radio Waves Act, Clause 3
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Input Specifications – 2080-IF2, 2080-IF4
Attribute 2080-IF2 2080-IF4
Number of inputs, single
ended
24
Analog normal operating
ranges
Voltage: 0…10V DC
Current: 0…20 mA
Resolution, max. 12 bits unipolar, with software selected option for 50 Hz,
60 Hz,
250 Hz, 500 Hz
Data range 0…65535
Input impedance Voltage Terminal: > 220K Ω, Current Terminal: 250 Ω
Overall accuracy
(1)
Voltage Terminal: ±1% full scale @ 25°C
Current Terminal: ±1% full scale @ 25°C
Non-linearity (in percent full
scale)
± 0.1%
Repeatability
(2)
± 0.1%
Module error over full
temperature range, -20…65°C
(-4…149°F)
Voltage: ± 1.5%
Current: ± 2.0%
Input channel configuration Through configuration software or the user program
Field input calibration Not required
Update time 180 ms per enabled channel
