Appendix A Specifications
North American temp code T4
Inrush current <120 mA @ 3.3V
<120 mA @ 24V
Backplane power 3.3 VDC, 38 mA
Output current, resistive 2 A @ 5…30V DC
0.5 A @ 48V DC
0.22 A @ 125V DC
2 A @ 125V AC
2 A @ 240V AC
Output current, inductive 1.0 A steady state @ 5…28V DC
0.93 A steady state @ 30V DC
0.5 A steady state @ 48V DC
0.22 A steady state @ 125V DC
2.0 A steady state, 15 A make @ 125V AC, PF – cos θ = 0.4
2.0 A steady state, 7.5 A make @ 240V AC, PF – cos θ = 0.4
Output power, resistive, max 250 VA for 125V AC resistive loads
480 VA for 240V AC resistive loads
60 VA for 30V DC resistive loads
24 VA for 48V DC resistive loads
27.5 VA for 125V DC resistive loads
Pilot duty rating C300, R150
Minimum load, per point 10 mA
Initial contact resistance of
relay, max
30 mΩ
Output delay time, max 10 ms ON or OFF
Relay Contact Ratings (0.35 power factor) – 2080-OW4I
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800 VA 180 VA
240V AC 7.5 A 0.75 A
24V DC 1.0 A 28 VA
125V DC 0.22 A
General Specifications – 2080-OW4I Digital Relay Output Plug-in Module
Attribute Value
