Specifications Appendix A
Output Specifications – 2080-OF2
Attribute 2080-OF2
Number of outputs, single
ended
2
Analog normal operating
ranges
Voltage: 10V DC
Current: 0…20 mA
Resolution, max. 12 bits unipolar
Output count range 0…65535
D/A Conversion Rate (all
channels), max.
2.5 ms
Step Response to 63%
(1)
5 ms
Current Load ln voltage
output, max
10 mA
Resistive load on current
output
0…500 Ω (includes wire resistance)
Load range on voltage output > 1k Ω @ 10V DC
Max. inductive load
(current outputs)
0.01 mH
Max. capacitive load
(voltage outputs)
0.1 µF
Overall Accuracy
(2)
Voltage Terminal: ±1% full scale @ 25 °C
Current Terminal: ±1% full scale @ 25 °C
Non-linearity (in percent full
scale)
± 0.1%
Repeatability
(3)
(in percent
full scale)
± 0.1%
Output error over full
temperature range,
-20…65°C (-4…149°F)
Voltage: ± 1.5%
Current: ± 2.0%
Open and short-circuit
protection
Yes
Output overvoltage protection Yes
Input group to bus isolation No isolation
Channel to channel isolation Non-isolation
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...65 °C (-4…149 °F)
Temperature, non-operating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal
Shock):
-40...85 °C (-40…185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% non-condensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
2g @ 10...500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
25 g
