Allen-Bradley micrologix 1500 User Manual

1 Publication 1764-UM001B-EN-P - April 2002
Appendix B
Replacement Parts
This chapter contains the following information:
• a table of MicroLogix 1500 replacement parts
• procedure for replacing the lithium battery
• illustrations of the MicroLogix 1500 replacement doors and
terminal blocks
MicroLogix 1500
Replacement Kits
The table below provides a list of replacement parts and their catalog
number.
Description Catalog
Number
Lithium Battery (See page B-2.) 1747-BA
ESD Barrier 1764-RPL-TRM1
Base Terminal Doors (See page B-6.) 1764-RPL-TDR1
Processor Access Door (See page B-6.) 1764-RPL-CDR1
Door Combination Kit, includes ESD Barrier, Terminal Door, Access
Door, Base Comms Door (See page B-6.), and Trim Pots/Mode Switch
Cover Door (See page B-6.)
1764-RPL-DR
17-Point Terminal Block (for inputs on 1764-24AWA and -24BWA
bases) (See page B-5.)
1764-RPL-TB1
21-Point Terminal Block (for inputs of 1764-28BXB and outputs for all
base units)(See page B-5.)
1764-RPL-TB2

Allen-Bradley micrologix 1500 Specifications

General

Processor Type	16-bit
Programming Language	Ladder Logic
Mounting	DIN rail or panel mount
Programming Software	RSLogix 500
Communication Ports	RS-232
Power Supply	24V DC
Operating Temperature	0°C to 55°C (32°F to 131°F)
Controller Type	Programmable Logic Controller (PLC)
