Allen-Bradley micrologix 1500

Publication 1764-UM001B-EN-P - April 2002
Wiring Your Controller 3-11
1764-24AWA Wiring Diagram
Input Terminals
Output Terminals
IN 9
NOT
USED
IN 0 IN 2
AC
COM 1
IN 5 IN 7 IN 8 IN 10
NOT
USED
AC
COM 0
IN 1
IN 3
IN 4
IN 6
AC
COM 2
IN 11
L2 L1
L1
L2
“NOT USED” terminals are not intended for use as connection points.
120/240
VAC
OUT 10OUT 8OUT 7OUT 5
VAC/
VDC 4
VAC/
VDC 3
VAC/
VDC 2
VAC/
VDC 1
VAC/
VDC 0
VAC
NEUT
OUT 11OUT 9
VAC/
VDC 5
OUT 6OUT 4OUT 3OUT 2OUT 1OUT 0
EARTH
GND
CR CRCR CR
CR CR
(Lo)
L2
(Hi)
L1
