Publication 1764-UM001B-EN-P - April 2002
Installing Your Controller 2-21
2. Align connector on the memory module with the connector pins
on the processor.
3. Firmly seat the memory module in the processor making sure
the locking tabs click into place.
4. Replace the cover (or DAT if used).
