2-24 Installing Your Controller
7. Attach an end cap terminator (5) to the last module in the
system by using the tongue-and-groove slots as before.
8. Lock the end cap bus terminator (6).
See Controller Dimensions on page A-9 for mounting dimensions.
IMPORTANT
A 1769-ECR right end cap (or a 1769-ECL left end cap
if I/O bank is located below the controller) must be
used to terminate the end of the serial
communication bus.
