11
SCHEMATIC DRAWING - PF400, STYLE C
75-100HP @ 460VAC
98D00718
JRF/ACI
4/8/04
JFH/ACI
4/8/04
4/8/04
NOTE:
IF THE "DRIVE/BYPASS ENABLE" RELAY,
CR, IS USED, RED JUMPERS "J1" AND "J2"
MUST BE REMOVED FROM RELAY CR.
L23
L21
SEE NOTE
DRIVE/BYPASS ENABLE
DRIVE
21
21
23
2422
24VAC
CR
22
RELAY
BC
24
23
14
OFF
TEST BYPASS
DOC
15
12
11
16
BC
13
BC
DOC
DIC
BYPASS
CONTACTOR
DRIVE
OUTPUT
CONTACTOR
INPUT
DRIVE
CONTACTOR
FU4 FU5
DM1
POWERFLEX 400
G
INCOMING
3
f POWER
L3
L2
L1
OPTO COMMON
RJ-45 SHIELD
#2 RELAY N.C.
#2 RELAY COMMON
#2 RELAY N.O. (MOTOR RUNNING)
#1 RELAY N.C.
#1 RELAY COMMON
OPTO OUTPUT (AT FREQUENCY)
ANALOG COM #2
#1 RELAY N.O. (READY/FAULT)
ANALOG INPUT #2
ANALOG INPUT #1
ANALOG OUTPUT #1 (FREQUENCY 0-10V)
ANALOG OUTPUT #2 (OUTPUT CURRENT 0-10V)
ANALOG COM. #1
DIGITAL INPUT 4 (COMM PORT)
DIGITAL COMMON
DIGITAL INPUT 3 (CLEAR FAULT)
DIGITAL INPUT 2 (LOCAL)
DIGITAL COMMON
DIGITAL INPUT 1 (PURGE)
SOFTWARE ENABLE
FUNCTION LOSS
RUN/FWD
12 435 867 910 16
+ 24VDC
+ 10VDC
1211 13 14 15 17 18 2019 R1 R4R2 R3 R5 R6
10V 20MA10V 20MA10V 20MA 10V 20MA
CONTROL BOARD
AO1 AO2 AI1
SNK
SRC
AI2
SS1
DOCCR
CR
43 44
31 33
J2-RED
SEE NOTE
20 19 31 20
CR
CR
14 13
22 21
J1-RED
19 20
SEE NOTE
DISCONNECT
SWITCH
MAIN
FU1
FU2
FU3
T3
T3
T1
T2
T2
T1
MOTOR
U/T1
BC
V/T2 W/T3
DOC
P1 P2
G
T3
T2
T1
R/L1 S/L2 T/L3
DIC
L13
L12
L11
