DATEREV. BY ECN/CR. NO.
A 11/24/04 JRF
B2/3/05 JRF
C 6/7/07 REH
D 8/10/07 REH
APPROVAL
DESIGN REVIEW
FOR MANUFACTURING
AS SHIPPED
AS COMMISSIONED
BYDATE
SH.NEXT
NO.SH.
-
DWG.ENG.
TITLE
CHK. BY
NO.DATE DATE
DR. BY
DATE
THIS DRAWING IS THE PROPERTY OF ROCKWELL AUTOMATION, INC.
OR ITS SUBSIDIARIES AND MAY NOT BE COPIED, USED OR DISCLOSED FOR ANY
PURPOSE EXCEPT AS AUTHORIZED IN WRITING BY ROCKWELL AUTOMATION, INC.
11
SCHEMATIC DRAWING - PF400, STYLE A
3-50HP @ 208VAC & 3-150HP @ 460VAC
98D00697
JRF/ACI
4/5/04
JFH/ACI
4/5/04
11/24/04
MAIN DISC.
SWITCH
LG
L3
INCOMING
3
f POWER
L1
L2
FU3
L13
FU2
FU1
L11
L12
P2P1
POWERFLEX 400
DM1
10V 20MA
RUN/FWD
FUNCTION LOSS
SOFTWARE ENABLE
DIGITAL INPUT 1 (PURGE)
DIGITAL COMMON
DIGITAL INPUT 2 (LOCAL)
DIGITAL INPUT 3 (CLEAR FAULT)
DIGITAL COMMON
DIGITAL INPUT 4 (COMM PORT)
1324 756 89
10V 20MA
CONTROL BOARD
AO2
10V 20MA
AO1 AI1
ANALOG COM. #1
ANALOG OUTPUT #2 (OUTPUT CURRENT 0-10V)
ANALOG OUTPUT #1 (FREQUENCY 0-10V)
ANALOG INPUT #1
+ 10VDC
+ 24VDC
ANALOG INPUT #2
#1 RELAY N.O. (READY/FAULT)
ANALOG COM #2
OPTO OUTPUT (AT FREQUENCY)
#1 RELAY COMMON
#1 RELAY N.C.
#2 RELAY N.O. (MOTOR RUNNING)
#2 RELAY COMMON
#2 RELAY N.C.
RJ-45 SHIELD
OPTO COMMON
151110 12 13 14 16 17 1918 20 R3R1 R2 R4 R5 R6
SRC
10V 20MA
AI2
SNK
DS1
JUMPERJUMPER
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
MOTOR
T3
T1
T2
GND
To Next Page
