Allen-Bradley PowerFlex 400 User Manual

B-4 Replacement Parts
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Bypass Parts
Components are manufactured by Allen-Bradley except as noted.
Terminal Lugs 208V AC 3.0…25 -
30…50 140U-J-TLA1
460V AC 3.0…60 -
75…125 140U-J-TLA1
150…200 140U-K-TLA1
250…300 140U-Q-TLA2
350 140U-M-TLA3
Style C Basic Bypass Packages
Motor Protector MP1 460V AC 3.0…5.0 140M-C2E-C10
7.5…10 140M-D8E-C16
15 140M-D8E-C25
20 140M-F8E-C32
25 140M-F8E-C45
30 140-CMN-4300
40 140-CMN-6300
50…60 140-CMN-9000
Disconnect Switch DS 460V AC 75…100 194R-NJ200P3
Main Fuses FU1…FU3 460V AC 75 AJT-175
(1)
100 AJT-200
(1)
Operator Handle 460V AC 3.0…60 140M-C-DN66
75…100 194R-HM1
Operator Shaft 460V AC 3.0…60 140M-C-DN66
75…100 194R-R4
(1) Manufactured by Gould-Shawmut.
Description Designation Voltage Hp Part Number
Description Designation Voltage Hp Part Number
Style B/N Full Feature Bypass Packages
Bypass Contactor BC 208V AC 5.0 100-C23D10
7.5…10 100-C37D00
15 100-C60D00
20 100-C72D00
25 100-C85D00
30…40 100-D110ED11
50 100-D180ED11
460V AC 3.0…10 100-C16D10
15…25 100-C37D10
30 100-C43D00
40…50 100-C72D00
60 100-C85D00
75 100-D110ED11
100 100-D140ED11
125 100-D180ED11
150 100-D180ED11
200 100-D250ED11
250 100-D300ED11
300…350 100-D420ED11

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
