Allen-Bradley PowerFlex 400 User Manual

Replacement Parts B-3
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Main Fuses
(continued)
FU1…FU3
460V AC 3.0 AJT-10
(1)
5.0 AJT-15
(1)
7.5…10 AJT-20
(1)
15…20 AJT-35
(1)
25 AJT-60
(1)
30 AJT-70
(1)
40 AJT-80
(1)
50 AJT-100
(1)
60 AJT-150
(1)
75 AJT-175
(1)
100 AJT-200
(1)
125 AJT-250
(1)
150 AJT-350
(1)
200 AJT-400
(1)
Style M/N Circuit Breaker Packages
Circuit Breakers CB1 208V AC 3 140U-H3C3-C15
5 140U-H3C3-C30
7.5 140U-H3C3-C40
10 140U-H3C3-C50
15 140U-H3C3-C80
20 140U-H3C3-D10
25 140U-H3C3-D12
30 140U-J3D3-D15
40 140U-J3D3-D20
50 140U-J6D3-D22
460V AC 3.0…5 140U-H6C3-C15
7.5 140U-H6C3-C20
10 140U-H6C3-C25
15 140U-H6C3-C35
20 140U-H6C3-C40
25 140U-H6C3-C50
30 140U-H6C3-C60
40 140U-H6C3-C80
50 140U-H6C3-D10
60 140U-H6C3-D12
75 140U-J6D3-D15
100 140U-J6D3-D20
125 140U-J6D3-D25
150 140U-K6D3-D30
200 140U-K6D3-D35
250 140U-Q6D3-D50
300 140U-Q6D3-D60
350 140U-M6D3-D70
Operator Handle Kit 208V AC 3.0…25 140U-H-RVM12B
30…50 140U-J-RVM12B
460V AC 3.0…60 140U-H-RVM12B
75…125 140U-J-RVM12B
150…200 140U-K-RVM12B
250…350 140U-M-RVM21B
Description Designation Voltage Hp Part Number

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
