Allen-Bradley PowerFlex 400 User Manual

3 Contactor Basic Bypass with Disconnect Package (Style C) 3-9
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Drawing Index 460V AC – 3 Contactor Basic Bypass with Disconnect Package (Style C)
Input
Voltage Type Hp
Input Line
Reactor
Drawing
HpSchematic Page Interconnect Page Layout Page Outline Page
460V AC
NEMA/UL
Type 1
3
No
98D00715
3-10
97D00711
3-13
95D00766
3-16 95D00706 3-20
3
5 5
7.5 7.5
10 10
15 15
20 20
25
98D00717
3-11
95D00767
3-17 95D00708 3-21
25
30 30
40 40
50
97D00713
3-14 95D00768 3-18
95D00710
3-22
50
60 60
75
98D00718
3-12 97D00714 3-15 95D00769 3-19
75
100 100

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
