Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Chapter 4
Mechanical Installation
Chapter Objectives
This chapter provides information on mounting a PowerFlex Drive Package
for Fan and Pump Applications.
Mounting Considerations
Environment
Before deciding on an installation site, verify that the PowerFlex Drive
Packages can be kept clean, cool and dry. The drives should be kept away
from oil, coolants or other airborne contaminants.
Maximum Surrounding Air Temperature
PowerFlex Drive Packages for Fan and Pump Applications are designed to
operate at 0…40 °C (32…104 °F) surrounding air temperature.
Minimum Mounting Clearances
Be sure there is adequate clearance for air circulation around the drive. For
best air movement, do not mount drives directly above each other. Note that
no devices are to be mounted behind the drive. This area must be kept clear
of all control and power wiring.
For information on … See page …
Mounting Considerations
4-1
Lifting and Mounting the Drive 4-4
Watts Loss 4-5
ATTENTION: The following information is merely a guide for
proper installation. The Allen-Bradley Company cannot assume
responsibility for the compliance or the noncompliance to any
code, national, local or otherwise for the proper installation of this
drive or associated equipment. A hazard of personal injury and/or
equipment damage exists if codes are ignored during installation.
