Allen-Bradley PowerFlex 400 User Manual

Mechanical Installation 4-5
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Watts Loss
The following table lists watt loss data for PowerFlex Drive Packages for
Fan and Pump Applications running at full load, full speed and a factory
default PWM frequency of 4kHz.
Table 4.A Watts Loss at Full Load/Speed, 4 kHz
Voltage kW Hp Total Watts
208V AC 2.2 3.0 180
3.7 5.0 220
5.5 7.5 308
7.5 10 375
11 15 498
15 20 660
18.5 25 744
22 30 788
30 40 1065
37 50 1210
460V AC 2.2 3.0 135
3.7 5.0 195
5.5 7.5 209
7.5 10 253
11 15 336
15 20 443
18.5 25 499
22 30 529
30 40 713
37 50 810
45 60 1132
55 75 1288
75 100 1560
90 125 1910
110 150 2310
132 200 3711
160 250 4208
200 300 4916
250 350 6167

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
