Allen-Bradley PowerFlex 400 User Manual

4-6 Mechanical Installation
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Weights
The following tables list weights for PowerFlex 400 Drive Packages for Fan
and Pump Applications. Weights are approximate.
Table 4.B Main Input Disconnect Package (Style A/M)
Voltage kW Hp Input Line Reactor
Weight
kg (lbs)
208V AC 2.2 3.0
No
13.2 (29)
3.7 5.0 13.2 (29)
5.5 7.5 13.2 (29)
7.5 10 13.2 (29)
11 15 Consult Factory
15 20 Consult Factory
18.5 25 42.2 (93)
22 30 42.2 (93)
30 40 68.0 (150)
37 50 Consult Factory
2.2 3.0
Ye s
Consult Factory
3.7 5.0 Consult Factory
5.5 7.5 Consult Factory
7.5 10 Consult Factory
460V AC 2.2 3.0
No
12.7 (28)
3.7 5.0 12.7 (28)
5.5 7.5 12.7 (28)
7.5 10 12.7 (28)
11 15 12.7 (28)
15 20 12.7 (28)
18.5 25 26.3 (58)
22 30 26.3 (58)
30 40 26.3 (58)
37 50 61.7 (136)
45 60 61.7 (136)
55 75 61.7 (136)
75 100 61.7 (136)
90 125 Consult Factory
110 150 Consult Factory
132 200 184.6 (407)
160 250 186.9 (412)
200 300 362.0 (798)
250 350 362.0 (798)
2.2 3.0
Ye s
18.6 (41)
3.7 5.0 18.6 (41)
5.5 7.5 18.6 (41)
7.5 10 18.6 (41)
11 15 25.9 (57)
15 20 25.9 (57)

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
