Allen-Bradley PowerFlex 400 User Manual

Mechanical Installation 4-7
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Table 4.C 3 Contactor Full Feature Bypass with Disconnect Package (Style B/N)
Voltage kW Hp Input Line Reactor
Weight
kg (lbs)
208V AC 2.2 3.0
No
18.6 (41)
3.7 5.0 18.6 (41)
5.5 7.5 Consult Factory
7.5 10 Consult Factory
11 15 39.9 (88)
15 20 39.9 (88)
18.5 25 93.0 (205)
22 30 93.0 (205)
30 40 Consult Factory
37 50 Consult Factory
2.2 3.0
Ye s
Consult Factory
3.7 5.0 Consult Factory
5.5 7.5 Consult Factory
7.5 10 Consult Factory
460V AC 2.2 3.0
No
18.1 (40)
3.7 5.0 18.1 (40)
5.5 7.5 18.1 (40)
7.5 10 18.1 (40)
11 15 24.5 (54)
15 20 24.5 (54)
18.5 25 34.9 (77)
22 30 34.9 (77)
30 40 34.9 (77)
37 50 131.5 (290)
45 60 131.5 (290)
55 75 131.5 (290)
75 100 131.5 (290)
90 125 Consult Factory
110 150 Consult Factory
132 200 322.1 (710)
160 250 324.3 (715)
200 300 392.4 (865)
250 350 408.7 (901)
2.2 3.0
Ye s
23.6 (52)
3.7 5.0 23.6 (52)
5.5 7.5 23.6 (52)
7.5 10 23.6 (52)
11 15 34.0 (75)
15 20 34.0 (75)

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
