Allen-Bradley PowerFlex 400 User Manual

Replacement Parts B-7
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Enclosure Parts
Description Designation Voltage Hp Part Number
NEMA/UL Type 1 (Style B only)
Control Transformer T1 208V AC 3.0…10 TB-69300
(1)
15…30 TB-69301
(1)
40…50 TB-69302
(1)
460V AC 3.0…20 TB-69300
(1)
25…60 TB-69301
(1)
75…300 TB-69302
(1)
350 TB-81215
(1)
Control Transformer Fuses FU4…FU5 208V AC 3.0…10 ATQR-1
(2)
15…30 ATQR-2
(2)
40…50 ATQR-3
(2)
480V AC 3.0…60 ATQR-1
(2)
75…300 ATQR-2
(2)
350 ATQR-3.5
(2)
NEMA/UL Type 12
Control Transformer T1 208V AC 3.0…10 TA-2-69301
(1)
15…20 TB-69302
(1)
25…50 TA-2-69302
(1)
460V AC 3.0…15 TA-2-69301
(1)
20 TA-2-69302
(1)
25…60 TB-69302
(1)
75…125 TA-2-69303
(1)
150 TA-2-69305
(1)
Control Transformer Fuse
Holder
208V AC 3.0…50 PL-112701
(1)
460V AC 3.0…60 PL-112701
(1)
75…125 PL-112702
(1)
150 PL-112704
(1)
Fan & Filter 208V AC 3.0…10 PF42500
(3)
15…20 PF43000
(3)
25…50 PF65000
(3)
460V AC 3.0…15 PF42500
(3)
20…40 PF43000
(3)
50, 60 & 125 PF65000
(3)
75 PF66000
(3)
100 & 150 PF67000
(3)
Exhaust Filter w/Grille 208V AC 3.0…20 PFA4000
(3)
25…50 PFA6000
(3)
460V AC 3.0…40 PFA4000
(3)
50…150 PFA6000
(3)
Filter Media 208V AC 3.0…20 18611600036
(3)
25…50 18611600037
(3)
460V AC 3.0…40 18611600036
(3)
50…150 18611600037
(3)

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
