Allen-Bradley PowerFlex 400 User Manual

B-8 Replacement Parts
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
NEMA/UL Type 3R
Control Transformer T1 208V AC 3.0…10 TB-69302
(1)
15…30 TA-2-69302
(1)
45…50 TA-2-69303
(1)
460V AC 3.0…5.0 TA-2-69302
(1)
7.5…20 TB-69302
(1)
25…40 TA-2-69302
(1)
50…100 TA-2-69303
(1)
125…150 TB-69303
(1)
Control Transformer Fuse
Holder
208V AC 3.0…30 PL-112701
(1)
40…50 PL-112702
(1)
460V AC 3.0…40 PL-112701
(1)
50…150 PL-112702
(1)
Fan & Filter 208V AC 3.0…10 SCE-FA44
(4)
15…30 SCE-FA66
(4)
40…50 SCE-FA1010
(4)
460V AC 3.0…5.0 No Fan
7.5…20 SCE-FA44
(4)
25…40 SCE-FA66
(4)
50…150 SCE-FA1010
(4)
Exhaust Filter w/Grille 208V AC 3.0…10 SCE-FGA44
(4)
15…30 SCE-FGA66
(4)
40…50 SCE-FGA1010
(4)
460V AC 3.0…5.0 No Filter
7.5…20 SCE-FGA44
(4)
25…40 SCE-FGA66
(4)
50…150 SCE-FGA1010
(4)
Filter Media 208V AC 3.0…10 SCE-RF44
(4)
15…20 SCE-RF66
(4)
25…50 SCE-RF1010
(4)
460V AC 3.0…5.0 No Filter
7.5…20 SCE-RF44
(4)
25…40 SCE-RF66
(4)
50…150 SCE-RF1010
(4)
Heater 208V AC 3.0…20 D-AH1001A
(5)
25…50 D-AH2001A
(5)
460V AC 3.0…40 D-AH1001A
(5)
50…150 D-AH2001A
(5)
NEMA/UL Type 4
Control Transformer T1 208V AC 3.0…20 TA-2-54525
(1)
25…30 TA-2-81202
(1)
40…50 TA-2-81203
(1)
460V AC 3.0…5.0 TA-2-69302
(1)
7.5…40 TA-2-54525
(1)
50…60 TA-2-81202
(1)
75…100 TA-2-81203
(1)
125…150 TA-2-69303
(1)
Description Designation Voltage Hp Part Number

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
