Allen-Bradley PowerFlex 400 User Manual

Replacement Parts B-9
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Control Transformer Fuse
Holder
208V AC 3.0…30 PL-112706
(1)
40…50 PL-112707
(1)
460V AC 3.0…5.0 PL-112701
(1)
7.5…60 PL-112706
(1)
75…100 PL-112707
(1)
125…150 PL-112702
(1)
Air Conditioner 208V AC 3.0 No Air Conditioner
5.0…10 IQ1800VS-126
(6)
15…20 IQ3000VS-126
(6)
25…30 IQ5000V16-126
(6)
40…50 IQ8000V16-126
(6)
460V AC 3.0…5.0 No Air Conditioner
7.5…20 IQ1800VS-126
(6)
25…40 IQ3000VS-126
(6)
50…60 IQ5000V16-126
(6)
75…100 IQ8000V16-126
(6)
125…150 DTS 3361
(3)
Filter Media 208V AC 3.0 No Filter
5.0…50 Media is washable
460V AC 3.0…5.0 No Filter
7.5…20 Media is washable
25 POF1019-GAL
(6)
30…100 Media is washable
125…150 18881500002
(3)
Heater 208V AC 3.0…30 D-AH1001A
(5)
40…50 D-AH2001A
(5)
460V AC 3.0…60 D-AH1001A
(5)
75…150 D-AH2001A
(5)
(1) Manufactured by Acme Electric.
(2) Manufactured by Gould-Shawmut.
(3) Manufactured by Pfannenberg Inc.
(4) Manufactured by Saginaw Control & Engineering
(5) Manufactured by Hoffman Enclosures Inc.
(6) Manufactured by Ice Qube Inc.
Description Designation Voltage Hp Part Number

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
