Allen-Bradley PowerFlex 400 User Manual

B-2 Replacement Parts
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Disconnect Parts
Components are manufactured by Allen-Bradley except as noted.
Line Reactors
(continued)
LR 460V AC 10 1321-3R18-B
15 1321-3R25-B
20…25 1321-3R35-B
30 1321-3R45-B
40 1321-3R55-B
50…60 1321-3R80-B
75 1321-3R100-B
100 1321-3R130-B
125 1321-3R160-B
150 1321-3R200-B
Description Designation Voltage Hp Part Number
Description Designation Voltage Hp Part Number
Style A/B Fused Disconnect Packages
Disconnect Switch DS 208V AC 3.0…5.0 194R-NJ30P3
7.5…10 194R-NJ60P3
15…20 194R-NJ100P3
25…40 194R-NJ200P3
50 194R-NJ400P3
460V AC 3.0…10 194R-NJ30P3
15…25 194R-NJ60P3
30…50 194R-NJ100P3
60…100 194R-NJ200P3
125…200 194R-NJ400P3
250 140U-Q6D3-D50
300 140U-Q6D3-D60
350 140U-M6D3-D70
Operator Handle
(NEMA/UL Type 1)
208V AC 3.0…10 194R-HS1
15…50 194R-HM1
460V AC 3.0…25 194R-HS1
30…200 194R-HM1
Operator Handle
(NEMA/UL Type 12, 3R, 4)
208V AC 3.0…10 194R-HS4
15…50 194R-HM4
460V AC 3.0…25 194R-HS4
30…200 194R-HM4
Operator Shaft 208V AC 3.0…10 194R-R2
15…50 194R-R4
460V AC 3.0…25 194R-R2
30…100 194R-R4
125…200 194R-R6
Main Fuses FU1…FU3 208V AC 3.0 AJT-20
(1)
5.0 AJT-20
(1)
7.5 AJT-35
(1)
10 AJT-40
(1)
15 AJT-80
(1)
20 AJT-100
(1)
25 AJT-125
(1)
30 AJT-150
(1)
40 AJT-200
(1)
50 AJT-250
(1)

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
