Allen-Bradley PowerFlex 400 User Manual

Replacement Parts B-5
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Input Contactor DIC 208V AC 3.0…7.5 100-C16D10
10…15 100-C37D00
20 100-C43D00
25…30 100-C72D00
40…50 100-D110ED11
460V AC 3.0…20 100-C16D10
25…30 100-C37D00
40 100-C43D00
50…60 100-C72D00
75 100-C85D00
100…125 100-D110ED11
150 100-D140ED11
200 100-D210ED11
250 100-D300ED11
300…350 100-D420ED11
Output Contactor DOC 208V AC 3.0…7.5 100-C16D10
10 100-C23D10
15 100-C37D00
20 100-C43D00
25…30 100-C72D00
40…50 100-D110ED11
460V AC 3.0…20 100-C16D10
25…30 100-C37D00
40 100-C43D00
50…60 100-C72D00
75 100-C85D00
100…125 100-D110ED11
150 100-D140ED11
200 100-D210ED11
250 100-D300ED11
300…350 100-D420ED11
Overload Relay OL 208V AC 3.0 193-EEDB
5.0 193-EEEB
7.5…10 193-EEFD
15…25 193-EEGE
30…50 193-EEJF
460V AC 3.0 193-EECB
5.0…7.5 193-EEDB
10 193-EEEB
15…30 193-EEFD
40…60 193-EEGE
75…150 193-EEJF
200…350 193-EELG
Bypass Control Panel CP1 208V AC 3.0…50 SK-C1-BCP1
460V AC 3.0…100 SK-C1-BCP1
Description Designation Voltage Hp Part Number

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
