Allen-Bradley PowerFlex 400 User Manual

Main Input Disconnect Package (Style A/M) 1-9
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
460V AC
NEMA/UL
Type 4
3
With or
Without
98D01537
1-15
97D01548
1-21
95D02442
1-41
95D01551
1-68
3
5 5
7.5
95D01563
1-42
7.5
10 10
15 15
20 20
25 95D01564
1-43 25
30
95D01565
1-44
30
40 40
50
95D01566
1-45
50
60 60
75
95D01567
1-46
75
100 100
125
98D01538
1-16 95D01568 1-47
125
150 150
NEMA/UL
Type 3R
3
With or
Without
98D01535
1-14 97D01548 1-21
95D01553
1-48
95D01550
1-69
3
5 5
7.5 7.5
10 10
15 15
20 20
25
95D01554
1-49
25
30 30
40 40
50
95D01555
1-50
50
60 60
75
95D01556
1-51
75
100 100
125
95D01557
1-52
125
150 150
Input
Voltage Type Hp
Input Line
Reactor
Drawing
HpSchematic Page interconnect Page Layout Page Outline Page

Allen-Bradley PowerFlex 400 Specifications

General

Input Voltage	200-240VAC, 380-480VAC, 500-600VAC
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Communication	EtherNet/IP
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5-95% non-condensing
Enclosure Rating	IP20
Horsepower	0.5-20 HP
Control Method	V/Hz, Sensorless Vector Control
