Electrical Installation 5-5
Rockwell Automation Publication 22C-IN002E-EN-P - November 2010
Installing the Required External/Separate Input Disconnect
An input disconnect must be installed in the line before the drive input
terminals in accordance with local, national, and international codes, such
as NEC/CEC. If an input disconnect is not installed as a factory option, the
disconnect should be sized according to the in-rush current as well as any
additional loads the disconnect might supply. The trip rating for the in-rush
current (10 to 12 times full load current) should be coordinated with that of
the input isolation transformer, if used.
Installing Input/Output Power Wiring
Table 5.C Style A Terminals
Table 5.D Style B Terminals
Table 5.E Style C Input Power Terminal Tightening Torque
208V AC Hp 480V AC Hp Maximum Tightening Torque
Input Power
3…5 1…10 12 lb•in
7.5…10 15…25 35 lb•in
15…20 30…50 35 lb•in
25…50 60…350 275 lb•in
Output Power
3…10 3…20 26 lb•in
15…30 25…40 45 lb•in
– 50…60 49.5 lb•in
40…50 75…150 173 lb•in
– 200…250 260 lb•in
– 300…350 354 lb•in
208V AC Hp 480V AC Hp Maximum Tightening Torque
Input Power
3…5 1…10 12 lb•in
7.5…10 15…25 35 lb•in
15…20 30…50 35 lb•in
25…50 60…350 275 lb•in
Output Power
3…7.5 3…7.5 13 lb•in
10…20 10…30 19 lb•in
25…30 40…75 40 lb•in
– 100…150 275 lb•in
40…50 200…300 500 lb•in
– 350 375 lb•in
208V AC Hp 480V AC Hp Maximum Tightening Torque
– 3…7.5 13 lb•in
– 10…30 20 lb•in
–4022 lb•in
– 50…60 120 lb•in
– 75…100 275 lb•in
Output Power
– 3…7.5 13 lb•in
– 10…30 19 lb•in
– 40…75 40 lb•in
– 100 275 lb•in
