B-6 Accessories and Dimensions
Table B.J Communication Option Kits and Accessories
Item Description Catalog Number
Communication
Adapters
Embedded communication options for use with
the PowerFlex 4-Class drives.
Requires a Communication Adapter Cover
(Ordered Separately).
ControlNet™
DeviceNet™
EtherNet/IP™
LonWorks™
PROFIBUS™ DP
22-COMM-C
22-COMM-D
22-COMM-E
22-COMM-L
22-COMM-P
External DSI™
Communications Kit
External mounting kit for 22-COMM cards. 22-XCOMM-DC-BASE
External Comms Power
Supply
Optional 100-240V AC Power Supply for External
DSI Communications Kit.
20-XCOMM-AC-PS1
Compact I/O Module Three channel. 1769-SM2
Communication Adapter
Cover
Cover that houses the Communication Adapter.
B Frame Drive
C Frame Drive
22D-CCB
22D-CCC
Universal Serial Bus™
(USB) Converter Module
Provides serial communication via DF1 protocol
for use with DriveExplorer and DriveTools SP
software. Includes:
2m USB cable (1)
20-HIM-H10 cable (1)
22-HIM-H10 cable (1)
1203-USB
Serial Converter Module
(RS485 to RS232)
Provides serial communication via DF1 protocol
for use with DriveExplorer and DriveTools SP
software. Includes:
DSI to RS232 serial converter (1)
1203-SFC serial cable (1)
22-RJ45CBL-C20 cable (1)
DriveExplorer Lite CD (1)
22-SCM-232
Remote Handheld HIM Wireless Interface Module with Bluetooth®
technology, IP30 (NEMA Type 1), Panel Mount
with optional bezel kit.
22-WIM-N1
Remote Panel Mount
HIM
Wireless Interface Module with Bluetooth®
technology, IP66 (NEMA Type 4X/12) indoor use
only.
22-WIM-N4S
DSI Cable 2.0 meter RJ45 to RJ45 cable, male to male
connectors.
22-RJ45CBL-C20
Serial Cable 2.0 meter serial cable with a locking low profile
connector to connect to the serial converter and a
9-pin sub-miniature D female connector to
connect to a computer.
1203-SFC
Null Cable Converter For use when connecting the serial converter to
DriveExplorer on a handheld PC.
1203-SNM
Splitter Cable RJ45 one to two port splitter cable AK-U0-RJ45-SC1
Terminating Resistors RJ45 120 Ohm resistors (2 pieces) AK-U0-RJ45-TR1
Terminal Block RJ45 Two position terminal block (5 pieces) AK-U0-RJ45-TB2P
DriveTools SP Software Windows based software packages that provide
an intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online.
Compatibility:
Windows 95, 98, ME, NT 4.0 (Service Pack 3 or
later), 2000, XP and CE
(1)
(1)
See www.ab.com/drives/driveexplorer.htm for supported devices.
9303-4DTS01ENE
DriveExplorer Software
(CD-ROM) Version 3.01
or later
9306-4EXP01ENE
DriveExecutive software
(CD-ROM) Version 1.01
or later
9303-4DTE01ENE
