Programming and Parameters 3-3
Basic Display Group
b001 [Output Freq] Related Parameter(s): b002, b010, P034, P035, P038
Output frequency present at T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0.00/P035
[Maximum Freq]
Display: 0.01 Hz
b002 [Commanded Freq] Related Parameter(s): b001, b013, P034, P035, P038
Value of the active frequency command. Displays the commanded frequency even if the drive is not
running.
Important: The frequency command can come from a number of sources. Refer to Start and Speed
Reference Control on page 1-27 for details.
Values Default: Read Only
Min/Max: 0.00/P035
[Maximum Freq]
Display: 0.01 Hz
b003 [Output Current]
The output current present at T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0.00/(Drive Rated Amps × 2)
Display: 0.01 Amps
b004 [Output Voltage] Related Parameter(s): P031, A084, A088
Output voltage present at terminals T1, T2 & T3 (U, V & W).
Values Default: Read Only
Min/Max: 0/Drive Rated Volts
Display: 1 VAC
b005 [DC Bus Voltage]
Present DC bus voltage level.
Values Default: Read Only
Min/Max: Based on Drive Rating
Display: 1 VDC
