3-22 Programming and Parameters
Advanced Program Group (continued)
A064 [Opto Out Logic]
Determines the logic (Normally Open/NO or Normally Closed/NC) of the opto outputs.
Values Default: 0
Min/Max: 0/3
Display: 1
A064 Option Opto Out1 Logic Opto Out2 Logic
0
1
2
3
NO (Normally Open)
NC (Normally Closed)
NO (Normally Open)
NC (Normally Closed)
NO (Normally Open)
NO (Normally Open)
NC (Normally Closed)
NC (Normally Closed)
A065 [Analog Out Sel] Related Parameter(s): P035, A066
Sets the analog output signal mode (0-10V, 0-20mA, or 4-20mA). The output is used to provide a
signal that is proportional to several drive conditions.
Values Default: 0
Min/Max: 0/20
Display: 1
Option
Output
Range
Minimum Output
Value
Maximum Output Value
A066 [Analog Out High]
DIP Switch
Position
Related
Parameter
0 “OutFreq 0-10” 0-10V 0V = 0 Hz P035 [Maximum Freq] 0-10V
b001
1 “OutCurr 0-10” 0-10V 0V = 0 Amps 200% Drive Rated Output Current 0-10V b003
2 “OutVolt 0-10” 0-10V 0V = 0 Volts 120% Drive Rated Output Volts 0-10V b004
3 “OutPowr 0-10” 0-10V 0V = 0 kW 200% Drive Rated Power 0-10V b022
4 “TstData 0-10” 0-10V 0V = 0000 65535 (Hex FFFF) 0-10V b019
5 “OutFreq 0-20” 0-20mA 0 mA = 0 Hz P035 [Maximum Freq] 0-20mA b001
6 “OutCurr 0-20” 0-20mA 0 mA = 0 Amps 200% Drive Rated Output Current 0-20mA b003
7 “OutVolt 0-20” 0-20mA 0 mA = 0 Volts 120% Drive Rated Output Volts 0-20mA b004
8 “OutPowr 0-20” 0-20mA 0 mA = 0 kW 200% Drive Rated Power 0-20mA b022
9 “TstData 0-20” 0-20mA 0 mA = 0000 65535 (Hex FFFF) 0-20mA b019
10 “OutFreq 4-20” 4-20mA 4 mA = 0 Hz P035 [Maximum Freq] 0-20mA b001
11 “OutCurr 4-20” 4-20mA 4 mA = 0 Amps 200% Drive Rated Output Current 0-20mA b003
12 “OutVolt 4-20” 4-20mA 4 mA = 0 Volts 120% Drive Rated Output Volts 0-20mA b004
13 “OutPowr 4-20” 4-20mA 4 mA = 0 kW 200% Drive Rated Power 0-20mA b022
14 “TstData 4-20” 4-20mA 4 mA = 0000 65535 (Hex FFFF) 0-20mA b019
15 “OutTorq 0-10” 0-10V 0V = 0 Amps 200% Drive Rated FLA 0-10V b029
16 “OutTorq 0-20” 0-20 mA 0 mA = 0 Amps 200% Drive Rated FLA 0-20 mA b029
17 “OutTorq 4-20” 4-20 mA 4 mA = 0 Amps 200% Drive Rated FLA 0-20 mA b029
18 “Setpnt 0-10” 0-10V 0V = 0% 100.0% Setpoint Setting 0-10V A109
19 “Setpnt 0-20” 0-20 mA 0 mA = 0% 100.0% Setpoint Setting 0-20 mA A109
20 “Setpnt 4-20” 4-20 mA 4 mA = 0% 100.0% Setpoint Setting 0-20 mA A109
