Allen-Bradley PowerFlex 6000T User Manual

70 Rockwell Automation Publication 6000-IN100A-EN-P - August 2020
Appendix E Line and Load Cable Sizes
(1) Cable sizes are based on overall dimensions of compact-stranded three-conductor shielded cable (common for industrial
cable tray installations). Maximum sizing stated accounts for minimum rated cable insulation requirements and the next
higher-rated cable (that is, 8 kV is not commercially available in many areas of the world, therefore Rockwell Automation
provides an 8 kV (minimum rating) and a 15 kV rating, when applicable. Enclosure openings accommodate the thicker
insulation on the higher-rated cable. IEC ratings show the equivalent to the NEMA sizes. The exact cable mm
2
size that is
shown is not commercially available in many cases; use the next smaller standard size.
(2) Minimum cable bend radius recommendations vary by national codes, cable type, and cable size. Consult local codes for
guidelines and requirements. General relationship of cable diameter to bend radius is typically between 7x...12x (for example,
if the cable diameter is 1 in. [2.54 cm] the minimum bend radius could range between 7...12 in. [18.8...30.48 cm]).
(3) As cabling methods can vary widely, maximum cable sizes that are shown do not account for the size of the conduit hub.
Verify size of conduit hubs against the “Drive enclosure openings” shown.
Table 18 - Line and Load Cable Sizes for B-Frame Drives (IEC and UL)
Description
(Motor V/Freq.)
Drive Enclosure
Opening mm (in.)
Max. Size and No. Incoming
Cables
(1) (2) (3)
(1) Cable sizes are based on overall dimensions of compact-stranded three-conductor shielded cable (common for industrial
cable tray installations). Maximum sizing stated accounts for minimum rated cable insulation requirements and the next
higher-rated cable (that is, 8 kV is not commercially available in many areas of the world, therefore Rockwell Automation
provides an 8 kV (minimum rating) and a 15 kV rating, when applicable. Enclosure openings accommodate the thicker
insulation on the higher-rated cable. IEC ratings show the equivalent to the NEMA sizes. The exact cable mm
2
size that is
shown is not commercially available in many cases; use the next smaller standard size.
(2) Minimum cable bend radius recommendations vary by national codes, cable type, and cable size. Consult local codes for
guidelines and requirements. General relationship of cable diameter to bend radius is typically between 7x…12x (for example,
if the cable diameter is 1 in. [2.54 cm] the minimum bend radius could range between 7…12 in. [18.8…30.48 cm]).
(3) As cabling methods can vary widely, maximum cable sizes that are shown do not account for the size of the conduit hub.
Verify size of conduit hubs against the “Drive enclosure openings” shown.
Maximum Line
Cable Sizes
2400V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
3000V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
3300V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
4160V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
6000V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 8 kV or
608 mm² (1200 kcmil) 15 kV/phase
6600V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 8 kV or
608 mm² (1200 kcmil) 15 kV/phase
7200V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 8 kV or
608 mm² (1200 kcmil) 15 kV/phase
10,000V, 50/60 Hz 138 x 138 (5.4 x 5.4) 608 mm² (1200 kcmil) 15 kV/phase
11,000V, 50/60 Hz 138 x 138 (5.4 x 5.4) 608 mm² (1200 kcmil) 15 kV/phase
Maximum Load
Cable Sizes
2300/2400V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
3000V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
3300V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
4000/4160V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 5 kV or
608 mm² (1200 kcmil) 8 kV/phase
6000V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 8 kV or
608 mm² (1200 kcmil) 15 kV/phase
6300/6600V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 8 kV or
608 mm² (1200 kcmil) 15 kV/phase
6900V, 50/60 Hz 138 x 138 (5.4 x 5.4)
608 mm² (1200 kcmil) 8 kV or
608 mm² (1200 kcmil) 15 kV/phase
10,000V, 50/60 Hz 138 x 138 (5.4 x 5.4) 608 mm² (1200 kcmil) 15 kV/phase
11,000V, 50/60 Hz 138 x 138 (5.4 x 5.4) 608 mm² (1200 kcmil) 15 kV/phase
