Press or keypads to highlight programmed temperature,
moisture/dryness, time or custom save. Press the or
keypads to edit the selected value of temperature, moisture, dry-
ness or time. All changes take effect immediately
, but don’t
change the saved cycle.
On Moisture Sensing models, pressing
while Custom Save
is highlighted will set the current actual moisture as the new pro-
grammed moisture for the running cycle. The current cycle will
then advance to the Cool Down segment and the control will re-
turn to Run Menu.
While running a Time Dry cycle, pressing while Custom
Save is highlighted will set the total elapsed cycle time as the
new programmed total cycle time. The current cycle will then ad-
vance to the Cool Down segment and the control will return to
Run Menu.
Cycle Stopped Menu
Cycle Stopped
Press START Key to Resume
Press STOP Key to Abort Cycle
3
2
1
TMB1357R_SVG
1. Cycle Stopped
2. Press STAR
T Key to Resume
3. Press STOP Key to Abort Cycle
Figure 12
The Cycle Stopped Menu will be displayed in Pause Mode. Press
to resume the cycle or to abort the cycle and go to the
Open Door Menu.
Cycle Stopped
Press BACK Key to Exit
Extended Tumble in 0:50
Cabinet High Limit Error
4
3
2
1
TMB1341R_SVG
1. Cycle Stopped
2. Extended Tumble in 0:50
3. Cabinet High Limit Error
4. Press BACK Key to Exit
Figure 13
The Cycle Stopped Menu will display an error, if one occurs, at
the end of a cycle or when is pressed. The time remaining
until Extended Tumble will be displayed. Press to exit to
go to Open Door Menu or open the door to go to the Cycle Menu.
Error Menu
Fan Motor Contactor Error
Press STOP Key to Abort Cycle
2
1
TMB1307R_SVG
1. Fan Motor Contactor Error
2. Press STOP Key to Abort Cycle
Figure 14
The Error Menu will be displayed as a result of an error during a
cycle, the Test Cycle or while on the Cycle Menu.
If a fatal error occurs during a cycle, the Error Menu display will
alternate with the Run Menu every three seconds until is
pressed or the Cool Down is complete.
Machine Cycle Definition and Operation
©
