STEP Test Cycle Step
Display
Description STEP ADVANCE COMMENTS
6 Heat Source Type of heat machine is con-
figured for
Press keypad.
DIP switch status will be
shown.
7 Reversing Motor
Present
Will show if machine is
equipped for reversing
Press keypad.
DIP switch status will be
shown.
8 Rotation Sensor
Present
Will show if machine is
equipped for rotation sensor
Press keypad.
DIP switch status will be
shown.
9 Moisture Sensor
Present
Will show if machine is
equipped for moisture sensor
Press keypad.
DIP switch status will be
shown.
10 Moisture Sensor Test
#1
Runs test for short in moisture
sensor circuit
(use orange jumper-shorted)
Press any keypad.
Press to restart test.
This step will be skipped if
machine is not equipped for
moisture sensor.
11 Moisture Sensor Test
#2
Runs test for resistance to ex-
pected moisture level
(use black jumper-resistance)
Press any keypad.
Press to restart test.
This step will be skipped if
machine is not equipped for
moisture sensor.
12
Ten Minute Cycle Runs a ten-minute normal cy-
cle
Press
keypad.
Any errors encountered are
displayed.
13 Audio Signal Test Audio signal sounds for five
seconds
Automatically
Table 3
Diagnostics
©
